POWER-AMP PCB PARTS LIST
Integrated Circuit
Reference Designator Description Material Number Note
Q1, Q3, Q6, Q8,
Q10-Q11, Q13-Q14
TRANSISTOR, MFET, N-CH, 600V, 18A,
DPAK
849830-0020
Q12, Q18 TRANSISTOR, MFET, N-CH, 0.3A, 60V,
SOT-23
356154-0010
Q16 TRANSISTOR, MFET, P-CH, 4A, 30V,
SOT23
357292-0020
Q2, Q7, Q19-Q21, Q32 TRANSISTOR, PNP, 40V, 0.6A, SOT-23,
MMBT4403
260354-001
Q4 TRANSISTOR, NPN, 40V, 0.6A, SOT-23,
2222A
326376-0010
Q5, Q15, Q17, Q22-Q26,
Q30
TRANSISTOR, NPN, 40V, 0.2A,
MMBT3904, SOT323
195357
Q9 TRANSISTOR, NPN, 3A, 50V, SOT89 852881-0010
Transistors
Reference Designator Description Material Number Note
U11, U16 IC, LIN REG, ADJ, SHUNT, TL431, 1%,
SOT23-3
330361-1030
U12 IC, DCDC CONV, BUCK, PWM, 1A, TSOT,
LV2843
842705-0010
U13 IC, VREG, LIN, POS, 5V, 78L05, SOT-89 856413-0010
U14 IC, VREG, SW, FLYBACK CNTRLR,
HF500-30, 7PDIP
855588-0010
U17 IC, VREG, LIN, NEG, 0.1A, 5V, TS79L-
05CY, SOT-89
856536-0010
U1X, U1Y, U1Z IC, PWR AMP, CLASS D, IRS2092, 16SO-
IC-N
855546-0010
U2X, U2Y, U2Z, U3X,
U3Y, U3Z
TRANSISTOR, MFET, N, 150V, 12.6A,
SIR622, SO8
847723-0100
U4-U5 IC, OPERATIONAL AMPLIFIER, 8SO,
NE5532
852382-0010
U6, U10, U15, U18 IC, OPTOCOUPLER, EL817, 4SO 326344-0020
U7 IC, PFC CONTROLLER, TRANS MODE,
UCC28063
730085-0030
U8 IC, SW, CNTRLR, HALF-BRIDGE,
HR1001A, 16SOIC
855754-0010
U9, U20 IC, OP AMP, DUAL, LM358, 8SOIC 856447-0010
