Bose Sub2 User Manual

28
Miscellaneous
POWER-AMP PCB PARTS LIST
Reference Designator Description Material Number Note
F1 FUSE, 12A, 250V, SLO-BLO, 5x20mm,
AXIAL
317834-123B 3
L12 INDUCTOR, POWER, SMT, 2.5A, 20%,
22uH, COMM
853388-220M
L2, L7 INDUCTOR, CUSTOM, RADIAL, 85uH 852652-0010
L4-L6 INDUCTOR, CUSTOM, RADIAL, 15mm
HEIGHT, 8.5mH
852653-0010
J1 CONN, HDR, 3.96mm C, 2P, 1R, P, TH,
RA, WHITE
847740-0020
J2 CONN, HDR, 2.54mm C, 28P, 2R, P, TH,
ST, 45.8H
847836-0028
J4 CONN, HDR, 3.96mm C, 2P, 1R, P, TH, ST,
WHITE
847743-0020
J7 CONN, HDR, 2mm C, 2P, 1R, P, SMT, RA 847747-0020
K1 RELAY, POWER, 10A, 1a/1c, CLASS B
INS
850873-0020
RT1 VARISTOR, METAL OXIDE, DIA 14mm,
300Vrms
856832-3000D 3
RT2 THERMISTOR, NTC, ICL, BULK, 20%, 10
ohm
856032-100MB 3
RT3-RT4 THERMISTOR, NTC, 0603, 3380K, 1%,
10K
855644-103F
T1 TRANSFORMER, CUSTOM, HTS-EEL25A 852657-0010 3
T2 TRANSFORMER, SWITCH, CUSTOM,
HTS-ER49B
852656-0010 3
