15
Using the EXP/CTL Jack
* When an EV-5 or FS-5U is connected to
the EXP/CTL jack, the PH-3’s own pedal
switch then only turns the effect on and off.
* When disconnecting from the EXP/CTL
jack, the RATE (tempo) settings used up to
that point are cleared, with the RATE knob
setting then becoming effective.
●
When Connecting the (Optional) Roland EV-5
The RATE settings can be adjusted with the EV-5.
You can change from the minimum RATE value set by the EV-5’s Minimum Value to
the value set with the PH-3’s RATE knob.
1.
Connect the EV-5 to the EXP/CTL
jack, and press the pedal completely
forward. The adjustment made with
the RATE knob in this condition
determines the maximum RATE
value when controlled with the EV-5.
2.
Return (raise) the pedal completely
back so the heel is down. The adjust-
ment made with the RATE knob at
this point determines the minimum
RATE value when controlled with the
EV-5.
