8
Feature Names and Functions
5. EXP/CTL Jack
Accepts connection of an expression ped-
al (Roland EV-5; sold separately) or mo-
mentary-type foot switch (BOSS FS-5U;
sold separately).
Use the EV-5 to change the RATE contin-
uously.
Setting tempos is easy with the FS-5U.
* Refer to “Using the EXP/CTL Jack” (p. 15).
6. Pedal Switch
Used for switching effects on/off, and for
inputting the tempo.
When the effect is on, be sure to start any
changes with the filter at the lowest setting.
* For inputting the tempo, refer to “Setting
the Tempo with the PH-3’s Pedal Switch”
(p. 13).
7. Thumbscrew
When this screw is loosened, the pedal
will open, allowing you to change the bat-
tery.
* For the procedure, refer to “Changing the
Battery” (p. 17).
