Boss Phase Shifter PH-3 - Page 16

16
Using the EXP/CTL Jack
● When Connecting the (Optional) BOSS FS-5U
The tempo can be set with the FS-5U.
Concerning how to make the tempo set-
tings, refer to steps 3 and 4 under “Setting
the Tempo with the PH-3’s Pedal Switch”
(p. 13). Simply substitute “FS-5U” where
it says “PH-3’s pedal switch.”
* The PH-3's pedal switch switches the
effect on and off. When the effect is on, the
CHECK indicator flashes alternately in
red and green.
* If you turn the RATE after setting the
tempo with the FS-5U, the RATE knob
value is then adjusted.
* You can also make the tempo settings
with the effect off.
* Set the polarity switch of the connected
the FS-5U as shown in the figure below.
Polarity switch
