FRONT PANEL
1. LCD Current Meter / Display
2. Overload error indicator light
3. Multi-function Control Knob
4. Positive Output Connection Socket
5. Negative Output Connection
6. Remote Controller Plug
7. Gas Output Connector
8. AC/DC Selection Switch
9. Welding Mode Selection Button
10. 2T / 4T Selection Switch
REAR PANEL
11. 240V AC Mains Power Switch
12. Gas Inlet Connector
13. Cooling Fan
14. 15 Amp Input Plug
3
4
10
9
8
2
1
5
13
6
11
7
12
14
DO NOT GRIND YOUR PLUG
This will void any warranty
on your machine
