3
CONTENTS PAGE
WARRANTY 4
BOX CONTENTS 5
WARNINGS 6
MACHINE CARE / SAFETY INSTRUCTIONS 7
WORK AREA SAFETY 8
MAINTENANCE & DISPOSAL / GAS BOTTLE
DUTY CYCLE 9
FRONT & REAR PANEL LAYOUT 10
MACHINE CONTROLS PANEL 11-12
MACHINE SPECS 13
GENERAL AC/DC WELDING 14
GENERAL PULSE WELDING 15
GENERAL 2T / 4T TRIGGER CONTROL 16
GENERAL LIFT ARC / HF START 16-17
CURRENT / REMOTE 17
CONTROL UPGRADE OPTIONS
STICK / MMA WELDING SETUP 18-19
ELECTRODE / CURRENT SELECTION 20
GENERAL MMA WELDING 21
STICK / MMA WELDING SETUP 19-20
GENERAL MMA WELDING 21
TIG WELDING SETUP 22-23
AC/DC WELD CYCLE SETUP 24-25
TUNGSTEN PREPARATION 26
GENERAL TIG WELDING 26-27
17 TIG TORCH BREAKDOWN 28
TROUBLE SHOOTING 29-31
