HF ARC START
FOOT CONTROL - OPTIONS
TORCH CONTROL - KIT OPTIONS
Bossweld Foot Control 3mt
Part No: 660201
3 metre cord
Ideal for bench work
Parent-Child relationship between the welder and foot controller.
This means if you set the welder to 120 Amps, the foot controller
range will be between min and 120 Amps.
Bossweld 26 series TIG torch
Part No: 95.26F.4.1.CC12A
The Bossweld 26 series TIG torch provides the operator
with maximum versatility and maneuverability.
The 26series models provide simple on/off gas switching
capabilities, and amperage control.
Lay the outside edge of the Gas
Cup on the work piece with the
Tungsten Electrode 1- 2mm from
the work piece.
1
Press the button on the TIG torch
2
The Arc will start forming an arc
between the tungsten tip and the
work piece
3
16
WARNING: CHECK ALL PARTS OF THE TIG TORCH
FOR DAMAGE BEFORE USE, ELECTRIC CURRENT
CAN BE DANGEROUS.
