Owner’s Manual
9
Item Qty Description Item Qty Description
A 32 Socket Hex Head Screw, M8x1.25x20 Black D 6 Flat Washer, M8x18 Black
B 32 Lock Washer, M8x14.8 Black E 24 Truss Phillips Head Screw, M5x16 Black
C 14 Phillips Head Screw, M4.2x16 Black F 6 Securing Ball
Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may be remaining Hardware
after the proper assembly of your machine.
Tools
Included
6mm #2
Hardware / Tools / Assembly
A B C D E
E F
To Next Page
