133
19.Usinga#2Phillipsscrewdriver,removethescrewsfromthe
Right and Left Shrouds. ( 3 screws on the Right Shroud, 9 on the
Left Shroud) Remove the upper screws labeled ‘ * ’ last.
20. Carefully remove the Shrouds from the machine.
If replacing the Right Fan Cover:
A.Usinga14mmopenfacewrench,removetheSecuringRing
from the outside of the Right Fan Cover.
B. Remove the Power Inlet from the inside of the Right Fan
Cover.
21. Installation is the reverse procedure.
22. Final Inspection
Inspect your machine to ensure that all hardware is tight and
components are properly assembled.
Do not use until the machine has been fully as-
sembled and inspected for correct performance in
accordance with the Owner’s Manual.
Right Side Left Side
*
*
Power Inlet
Securing Ring
