52
13.Usinga#2Phillipsscrewdriver,attachthenewConsoleRearPaneltotheConsole
Front Panel.
14.Installationisthereverseprocedure.
Note: DonotcutorcrimptheCables.EachCableconnector(3-pin,4-pin,5-pinand12-
pin) has a corresponding end connector with that many openings. Be sure to fully connect
the cable connectors.
15. Final Inspection
Inspect your machine to ensure that all hardware is tight and components are properly
assembled.
Do not use until the machine has been fully assembled and inspected for
correct performance in accordance with the Owner’s Manual.
