Bowflex Max Total 16/40 - Page 63

63
Note: Your machine may not match the images provided exactly.
1. Unplug the AC Adapter from the wall outlet and machine.
3. Using a 6mm hex wrench, remove the indicated hardware from the Up-
per Handlebars and place them out of the work area.
Note: Be aware that the Upper Handlebars must be supported when
removing the hardware.
2.Usinga#2Phillipsscrewdriver,removethe4screws(2indicatedon
one side) from the Upper Shroud and remove it.
4.RemovetheRightandLeftStabilizerShroudsfromthemachine(if
equipped).
Right Stabilizer
Shroud
Left Stabilizer
Shroud
Upper Shroud
Left Upper
Handlebar
Right Upper
Handlebar
