Bowflex Max Total 16/40 - Page 68

68
1. Unplug the AC Adapter from the wall outlet and machine.
2. Using a 5mm hex wrench, remove the indicated hardware from the Left
Upper Handlebar and place it out of the work area.
Note: Be aware that the Upper Handlebar must be supported when
removing the hardware.
2.Usinga#2Phillipsscrewdriver,removethe4screws(2indicatedon
one side) from the Upper Shroud and remove it.
4.RemovetheRightandLeftStabilizerShroudsfromthemachine.
Right Upper
Handlebar
Right Stabilizer
Shroud
Left Stabilizer
Shroud
Upper Shroud
