Bowflex Preacher Curl Attachment - Step 7: Mount Bicep Curl Pad on Lower Sub-assembly

12
Assembly Instructions
Parts:
• Bicep Curl Pad Assembly from Step 6
• Preacher Curl Sub-assembly from Step 5
Assembly Steps:
7-1 Insert the Bicep Curl Pad Assembly in the mount
on the Preacher Curl Sub-assembly, as shown in
Figure 7.
7-2 Adjust the Bicep Curl Pad Assembly to the desired
height and secure with the pop pin.
STEP 7: Mount Bicep Curl Pad on Lower Sub-assembly
Figure 7 - (only one squat pulley shown)
Pop pin
