Bowflex Preacher Curl Attachment - Step 6: Bicep Curl Pad Assembly

11
Assembly Instructions
Figure 6
STEP 6: Bicep Curl Pad Assembly
Parts:
• (1) Seat Post - Item 6
• (1) Pad - Item 7
Hardware:
• (4) 5/16” X 1” Hex Bolts - Item 13
• (4) 5/16” Washers - Item 15
Tools:
• 3/16” Hex Wrench
Assembly Steps:
6-1 Attach the Pad (7) to the Seat Post (6) using the
hardware shown. See Figure 6.
6-2 Tighten hardware.
13
15
7
6
