Step 2.
Note: Hardware for this step is on the 2080 Stand hardware card. Fully tighten the hardware. Turn the Base assembly right side up and adjust the Leveler Feet so that the assembly
is level and stable.
A
C
B
6mm
X4
1
1
4 X4
5 X4
X4
D
E
3mm
6
6
Step 3.
Note: Hardware for this step is on the 2080 Barbell with Curl Bar hardware card, not the 2080 Stand hardware card. Do not fully tighten screws. Shrouds should still slide.
NOTICE: Use the inner set of screw holes in the Base Tubes to t the 80-lb barbell conguration. If the Barbell will have the 40-lb Weight Upgrade (the 120-lb conguration), use the
outer set of screw holes in the Base Tubes.
10
A
6mm
X8
10
Inner
Outer
Item Qty Description
1 2 Stabilizer
4 4 Leveler Foot
5 4 Endcap
6 2 Gusset
Item Qty Description
10 2 Base End Shrouds
Assembly / Owner’s Manual
7
