BOXER 322D - Operating Controls

Operating Controls
2.3
Operating Controls
Item No. Description
1 High/Low selector control
2 Hand grip
3 Attachment tilt control
4 Right travel motor control
5 Left travel motor control
6 Loader arm lift control
7 Engine throttle
8 Auxiliary attachment activation control/Operator presence
9 Engine temperature indicator light
10 Engine oil pressure indicator light
1
2345627
8
910
