BOXER 322D - Vibration Data; Noise Data

General Specications
6.2
Units English Metric
Dump Angle 34 deg. 34 deg.
Reach 28 in. 711 mm
Tip Capacity 1325 lb. 601 kg
Operating Capacity, 35% of tip load. 464 lb. 210 kg
Operating Capacity, 50% of tip load. 663 lb. 301 kg
Weight (without Bucket)(*w/Bucket) 1900 lb. 862 kg
Ground Pressure 3.3 psi 22.6 kPa
Vibration Data
Engine rpm was set @ 3,000 rpm. The hand-arm and whole body vibration measurements
were made with the operator present.
Vibration Test @ hand /arm: Declared value is 5.1 m/s
2
.
Vibration Test @ whole body: Declared value is 0.4 m/s
2
.
Noise Data
Tests were performed in accordance with EU Directive 2000/14/EC, in addition to ISO 3744
and ISO 6395. Engine rpm was set @ 3,000 rpm. The noise measurements were made with
the operator present.
The declared value for the operator is 89 dB L
PA
.
The Guaranteed SWL value is 101 dB L
WA
.
