BOXER 322D - Section 6 - General Specifications

6.1
Section 6 - General Specications
Engine System
Type
Kubota, Command Pro
Cooling System
Liquid Cooled
HP / KW
22 / 14.9
Fuel Tank
4.5 Gallons
Air Cleaner
Heavy duty, 2 stage, remote mounted
Hydraulic System
Pressure (Auxiliary/Boom & Tilt Cylinder Circuit)
3000 psi system relief
Pressure Ground Drive Circuit
3000 psi system relief
Flow Auxiliary
9.4 GPM (High) 3 GPM (Low) @ 3600 rpm
Flow Ground Drive
9.4 GPM (High) 3 GPM (Low) @ 3600 rpm
Reservoir Capacity
16 gallons
Filter
10 Micron
Electrical System
Battery
12 Volt
Control System
Starting
Keyed ignition switch.
Throttle/Choke
Remote Mount Throttle
Steering
Two spring centered control lever with zero turning
type controls.
Boom/Loader Arms
Three position, spring centered lever control. Up,
neutral, down.
Bucket/Attachment Tilt
Three position, spring centered lever control. Ex-
tend, neutral, and curl.
Auxiliary/Attachment Control
Two position, detented, Third position spring return
to neutral.
Track Options
7” Wide Track
Drive Train
Two Wheel Motors
Operator Platform
Suspended Stand On Platform
Mount Plate
Universal CUL Attachment Plate
Warranty
Engine Warranty
Two Year
Product Warranty
One Year
Ground Drive System-Dimensions
Units English Metric
Wheelbase 32 in. 813 mm
Ground Clearance 5.0 in. 127 mm
Overall Length (w/ Bucket 3101400) 87 in. 2210 mm
Overall Length (without Bucket) 68 in. 1727 mm
Overall Width 34.5 in. 876 mm
Overall Height 49 in. 1235 mm
Overall Operating Height (Fully Raised) 92 in. 2337 mm
Hinge Pin Height (Fully Raised) 70 in. 1765 mm
Dump Height 54 in. 1372 mm
Ground Speed (Max) 3.4 mph 5.5 kph
