BOXER 322D - Removal of Attachment

Pre Start Inspection and Operation
3.23
Removal of Attachment
1. Lower the attachment onto a rm, level surface.
2. Shut o the machine engine.
3. Rotate the attachment lock pins to the UNLOCKED position (Item 1, Figure 3–30).
Figure 3-30 Attachment Locks in Unlocked Position
4. Start the engine and rotate the mounting plate downwards.
5. Back away from the attachment.
NOTE: It may be necessary to lower the loader arm assembly slightly to fully disengage
from the attachment.
1
1
Pins Unlocked
