Installation LD-3010 Series
Bradley • 215-1219 Rev. Q: ECO 19-08-037B 2/27/2020 5
Standard Height
(HS-TO1
Undermount
Bowl)
16½"
(418)
9"
(229)
22"
(559)
17"
(432)
Standard Height
(HS-TS1
Undermount
Bowl)
27"
(686)
34"
(864)
16½"
(418 )
9"
(229)
22"
(559)
27"
(686)
34"
(864)
17"
(432)
Dimensions - Side View (mm)
Juvenile Height
(HS-TO1
Undermount
Bowl)
9"
(229)
22"
(559)
17"
(432)
24"
(610)
31"
(864)
Juvenile Height
(HS-TS1
Undermount
Bowl)
13½"
(418)
9"
(229)
22"
(559)
24"
(610mm)
31"
(787)
17"
(432)
Surface mount brackets shown. Also available with carrier
sleeves for concealed in wall carriers.
13½"
(418)
