Printer Media Compartment
Figure 4 shows the components inside the media compartment of your printer. Depending on
installed options, your printer may look slightly different.
Figure 4 • Printer Components
Note • For optimal printing quality and proper printer performance across our product line,
Brady strongly recommends the use of genuine Brady supplies as part of the total solution.
Specifically, the BBP81 is designed to work only with genuine Brady printheads, thus
maximizing safety and print quality.
1
Printhead assembly
5
Ribbon take-up spindle
2
Control panel
6
Ribbon supply spindle
3
Media door
7
Dancer assembly
4
Media supply spindle
8
Printhead release latch
