Scan Rate: This is scroll time for the display pages. Select time interval between 5 sec
to 30 sec. This time set is effective only if idle time is enabled selecting time between 1
to 10 min
LCD:
Brightness: Select level between 0 and 6. 0 is lowest brightness and 6 is for highest
possible brightness
Screensaver: To prolong the life of the LCD display, it is suggested to set the display
turn-off time in 1, 10, 20, 30, 40, 50 or 60 minutes after the user operates the
recorder. It was initially set 10 minutes for Screensaver from the factory. The
recorder continues to record data while it is in the screen saving mode. The display
turns on again by touch on the LCD screen
Storage: Select internal flash memory or SD card
Custom page:
Allow download via Ethernet: Enable/disable
4.7 Security
4.7.1 Normal
Path: (Menu)-More-Config-select Instrument, then press “Enter”
Select “Security” = Normal
If the normal security is selected, for different users it needs just to key in a common
password in maximum 18 characters. Once the password has been entered, the user
needs to key in the password whenever Config, Dump, Clear or Operate soft keys are
required. These keys enable the user to do configuration, dump data, clear data or
manually operate the job. For easy access Config, Dump, Clear or Operate soft keys,
the user may ignore the password.
How to enter simple password
(Menu)-More-Config, select Password, press “Enter”, then key-in the password
108
