13 Udballing USA.fm • Page 31Bale press X-series
13 Ejecting the bale
When the two orange finish indicator buttons light and
thus indicate that the bale is going to be ejected, check
the following:
The main door must be open at least 90° in relation to
the chamber.
There must not be any materials jammed in the ejection
system, since this will prevent the press from ejecting
the bale.
The ejection mechanism on the platen must be pushed
completely forward. If it is pushed back, the jammed
material must first be removed.
Important! First remember to disconnect the power
by removing the plug from the electric socket. If this
cannot be done, a padlock must be placed on the
baler’s repair switch.
Then reset the press with a single push of the green start
button.
> 90°
