42hW-201601

CHAPTER 4 TRANSMISSION

3015R(h)/3515R(h)/4015R(h)/F36R(h)/F42R(h) TRACTOR

3.2.3 BRAKE PEDAL FREE PLAY ADJUSTMENT

)UHHSOD\

F42W129A

Depressthebrakepedal(1)slightly.Then,releaseit.

Measureitsfreeplay.

ITEM STANDARD

Brakepedalfreeplay 5-10mm(0.19-0.39in)

*Thefreeplayforbothpedalsshouldbeidentical.

3. Ifthefreeplayisoutofthestandard,unscrewthe

mounting nuts (2) of the brakerods (LH/RH) on

the brake shaft section and use the turnbuckle

(3)toadjustthefreeplay.Afteradjustingthefree

playofthebothsides,tightenthemountingnuts.

F42W130A

MEC. MODEL

A42W409B

HST MODEL
