CHAPTER 7 ELECTRIC SYSTEM
7
3015R(h)/3515R(h)/4015R(h)/F36R(h)/F42R(h) TRACTOR
F42W727A
5.2.17 COOLANT TEMPERATURE SENSOR (METER)
 

      


K20W741A
RESISTANCE BY COOLANT TEMPERATURE
▶
TEMPERATURE
(°C)
  80   115  
RESISTANCE
(K Ω )
       
MEASURING CIRCUIT
▶
K20W742A


alvano-
meer
5.2.18 FUEL CUT-OFF SOLENOID
       
       


SPECIFICATION
▶
RATED VOLTAGE 12 V
POWER CONSUMPTION 16 W
START VOLTAGE 6.5 V
HOLDING VOLTAGE 2.5 V
OPENING VOLTAGE 0.5 V
F42W728A
K20W744A
