Branson 3515r - Page 227

4
-
55
42hW-201601
CHAPTER 4 TRANSMISSION
4
3015R(h)/3515R(h)/4015R(h)/F36R(h)/F42R(h) TRACTOR
K42W449A
K20W4A05
K42W450A
K42W451A
K42W452A
        
      

•

PTO CLUTCH PACK COMPONENTS
DISASSEMBLY
▶
10.Unscrewthe plug (1)and removethe springand
steelball.Then,removethemainshiftforkcover(2).
11.Pull out thespring pin(1) and removethe main
shiftforkshaft,mainshiftfork(1-2nd)(2),(3-4th)(3)
andanti-pairingpin(4).
