Page 28
B-3202-0106 Hydraulic Pump:
Fixed displacement external gear
type hydraulic pump with 12 VDC
electric motor and 76 cubic inch
ÁXLGUHVHUYRLUIRU9%)<
Hydraulics
Hydraulic Fluid: Use Braun
47K\GUDXOLFÁXLG([[RQ
®
Univis HVI 26). Do not mix with
'H[WURQ,,,RURWKHUK\GUDXOLFÁX-
LGV&KHFNÁXLGOHYHOZLWKUDPS
DEPLOY and STOW PRESSURE ADJUSTMENT
fully deployed. Fill to maximum
ÁXLGOHYHOLQGLFDWHGRQUHVHUYRLU
ÀOOOLQHPROGHGLQUHVHUYRLU'R
QRWRYHUÀOO
Deploy and Stow Pressure Relief Valves
Deploy and stow pressure relief valves are
factory set and typically should not require
DGMXVWPHQW$GMXVWPHQWSURFHGXUHW\SLFDOIRU
both valves. 7KHUDPSSDQFRYHUVXEÁRRU
must be removed to access relief valves.
Relief Valve Adjustment Procedure
1. Insert a 3/16 Allen wrench into the Allen
DGMXVWPHQWVFUHZ6HFXUHWKH$OOHQVFUHZ
and loosen the hex nut (do not remove hex
nut).
2. Place 40 pound load on ramp (at center).
3. Turn the Allen screw clockwise until pump
starts to lift the load.
4. Turn the Allen screw counterclockwise 1/4
turn.
5. Remove load from platform. Verify pump
will lift empty ramp.
6. Secure the Allen head screw and tighten
the hex nut securely.
Contact The Braun
Corporation before
adjusting hydraulic
pressure relief valve.
Failure to do so may
result in serious
bodily injury and/or
property damage.
Figure N
Stow (A)
Pressure
Relief Valve
Deploy (B)
Pressure
Relief Valve
Hex Jamb Nut
Allen
Screw
