Maintenance and Lubrication Schedule
Roll stop pivot bearings (2)
Roll stop latch pivot point
Roll stop latch slot
Roll stop lever bearings (2)
Lift-Tite
™
latches (tower pivot points - 2)
Lift-Tite
™
latch gas (dampening)
spring pivot points (2 springs - 4
points)
Inspect Lift-Tite
™
latches and gas
springs for wear or damage (bent,
deformed or misaligned), positive
securement (external snap rings) and
proper operation
Roll stop for proper operation
Inspect roll stop latch for proper
operation, positive securement, and
detached or missing spring
Adjust fold pressure
Inspect lift for wear, damage, or any
abnormal condition
Inspect lift for rattles
Apply Light Oil - See Lubrication
Diagram
Apply Light Oil - See Lubrication
Diagram
Apply Light Grease to both sides of slot.
See Lubrication Diagram
Apply Light Oil - See Lubrication
Diagram
Apply Light Oil - See Lubrication
Diagram
Apply Light Oil - See Lubrication
Diagram
Resecure, replace damaged parts or
otherwise correct as needed. Note:
Apply Light Grease to Lift-Tite
™
latch
tower pivot point if replacing latch.
Correct or replace damaged parts.
Correct or replace damaged parts and/
or relubricate. See Lubrication Diagram
See service manual
Correct as needed.
Correct as needed
750
Cycles
Apply grease (synthetic) to contact
areas between upper/lower fold arms.
See Lubrication Diagram.
Apply Light Oil - See Lubrication
Diagram
Apply Light Oil - See Lubrication
Diagram
Apply Light Oil - See Lubrication
Diagram
Apply Light Oil - See Lubrication
Diagram
Upper/Lower fold arms
Platform pivot pin bearings (4)
Inner fold arm bearings (8)
Bridge plate lever bearings (2)
Bridge plate lever slot (2)
1500
Cycles
