Page 35
Apply Light Oil - See Lubrication
Diagram
Apply Light Oil - See Lubrication
Diagram
Apply Light Oil - See Lubrication
Diagram
Apply Light Oil - See Lubrication
Diagram
Apply Light Oil - See Lubrication
Diagram
Correct, replace damaged parts and/or
relubricate.
Resecure, replace or correct as needed.
See Platform Angle Instructions
and Tower Microswitch Adjustment
Instructions. See service manual.
Replace damaged parts
Resecure, replace or adjust as needed
(see applicable service manual).
Realign towers and vertical arms.
Lubricate or correct as needed.
Resecure or replace if needed.
Apply Light Oil - See Lubrication
Diagram
Correct or replace damaged parts
Bridge plate pivot bearings (2)
Saddle support bearings (8)
Parallel arm pivot pin bearings (16)
Handrail pivot pin bearings (4)
Hydraulic cylinder pivot bushings (8)
Inspect Lift-Tite
™
latch rollers for wear
or damage, positive securement and
proper operation (2)
Inspect bridge plate for:
• Wear or damage
• Proper operation. Bridge plate should
just rest on top surface of the base
plate cover.
• Positive securement (both ends)
Inspect switch arm components for
wear or damage, and for proper
operation
Inspect microswitches for securement
and proper adjustment
Make sure lift operates smoothly
Inspect external snap rings:
• Inner fold arm (6)
• Lift-Tite
™
latch roller (2)
• Lift-Tite
™
latch gas (dampening)
spring (4)
• Outer fold arm roller pins (4)
• Outer fold arm cam followers (4)
• Outer barrier hydraulic cylinder
mounting pin (2)
• Bridge plate lever bracket pins (2)
• Saddle support pins (2)
Side entry hinge pivot points
Inspect side entry for proper operation,
positive securement, and wear or
damage to nylon belt and roller chain
1500
Cycles
Maintenance and Lubrication Schedule
