Page 10
TROUBLESHOOTING
FUNCTION SYMPTOM POSSIBLE CAUSE REMEDY
8.20
Faulty
Operation
6.00
POWER
DOOR
(CLOSE)
6.11 See 3.10, 4.12 and 5.12
6.12 Power slide door module (PSDM)
did not see stowed signal
6.21 See 3.20
6.31 See 3.30
6.41 See 3.30
6.42 Ramp obstructing door
6.51 Ramp Stow Position microswitch
out of adjustment
6.52 See 4.40, 5.12 and 5.20
7.00
KNEEL
SYSTEM
(RAISE)
7.20
Faulty
Operation
7.10
No Raise
Operation
8.10
No Operation
6.30
Faulty
Operation
6.40
Door Does
Not Close
Fully (Door
Kickback)
6.50
Door Contacts
Ramp When
Closing
6.10
No
Close
Operation
6.20
Motor Runs - Door
Does Not Move
8.00
KNEEL
ELECTRICAL
OVERRIDE
(RAISE)
7.11 See 1.00, 2.12, 2.13, 2.14, 2.15
and 2.17
7.12 Kneel Raised microswitch har-
ness disconnected/damaged or
microswitch damaged
7.21 See 2.20
8.11 See 1.10, 2.13, 2.14, 2.15 and
2.17
8.21 See 2.20
Correct or contact Braun Product
Support
Adjust ramp Stow Position micro-
switch inward (toward cabin area)
Adjust Ramp Stow Position micro-
switch inward (toward cabin area)
Connect/repair harness or replace
microswitch
9.20
Faulty
Operation
9.10
No Operation
9.00
RAMP
ELECTRICAL
OVERRIDE
(STOW)
9.11 See 1.10, 4.13, 4.14 and 4.16
9.21 See 4.13, 4.32, 4.33, 4.41, 4.42
and 4.43
To Next Page
