Page 6
Perform all procedures listed in previous section also
6 Months
Power Fold Ramps:
• Ramp flap (extension) chain
Remove ramp housing cover/rear vertical panel
and inspect:
• Top mount bracket bolts for securement
(loose or missing)
• Motor mounting bolts for securement (loose
or missing)
• Ramp fold arm securement (collar and
mounting screws)
• Microswitches securement and adjustment
• Microswitch wires and terminals for secure-
ment or damage
• Magnetic switch (optional)
Inspect power source: Vehicle battery, 50
ampere fuse, vehicle engine compartment fuse
block and driver side under dash-mounted fuse
block.
Inspect kneel actuator assembly for:
• Actuator mounting pin securement (micro-
switch activation block)
• Inspect chain for misalignment, wear or
damage
• Inspect chain master-links for securement
• Inspect chain idler (pulley) for securement,
wear, damage or misalignment
• Inspect electrical harnesses for positive
connections, proper routing, wear or other
damage
• Kneel microswitch(es) securement, wear or
other damage
Kneel electrical override
Kneel assembly chain
Lubricate with Anti-Seize (14 oz. caulk tube
available per Braun part no. 24710)
Resecure, adjust microswitches, replace dam-
aged parts or otherwise correct as needed.
Note: See 2008 Foldout Ramp Exploded views
on pages 19B-20B, 23A-24A and 23B-24B.
Resecure, repair or replace
Realign, resecure, replace damaged parts or
otherwise correct as needed. Note: See Kneel
Actuator Assembly exploded view on page 27.
Check operation
Lubricate with Anti-Seize (14 oz. caulk tube
available per Braun part no. 24710)
MAINTENANCE and SERVICE
Maintenance and Lubrication Schedule
Consecutive
3 Month
Intervals
Repeat all previously listed inspection, lubrica-
tion and maintenance procedures at 3 month
intervals.
To Next Page
