Page 21
2008 Chrysler XT Conversion (Foldout Ramp) Platform Assembly
1 1 RAMP-EXTENSION/29.25" AUTO/2008 CHRYSLER E50262??-08
2 1 RAMP-BASE/29.25"AUTO/08RT E51095??
3 2 SCREW-#10-32X1/2 FHDHXS-AUTO BLK-W/PATCH 17192P
4 2 NUT-#10-32 W/LOCKWASHER/AUTO-BK 18349
5 1 HINGE WMT.-S.S. 2" X 1/4" X 29" 18619W029
6 2 WASHER-1/4" FLAT/AUTO-BK 10062
7 2 BOLT-1/4-20X3/4"BHCS NYLK/BKZN 25371
8 1 CAM-CAST RAMP 34317
9 2 BUMPER-RUBBER RECES.31/32 OD 10950
10 1 CHAIN-NICKEL PLATED #35 ROLLER X 9.38" 84314R009.38
11 2 LINK-CHAIN #35 12454
12 1 BRACKET-CABLE TENSIONER/OUTER/BLACK 52568-2908BK
13 1 DECAL-WARN CHAIN HAZ RAMP EVII 26134
14 3 #6 NYLON WASHER 82070-000
15 0.001 LOCTITE-BLUE/#242 GEN PURPOSE 18822
16 1 SHRINK TUBING-1/2" x 7" LONG 14374R007
17 20 NUT-10-32 HEX CENTER LOCK/AUTO-BK 34290BK
18 20 SCREW-#10-32 X 5/8" FHSC-AUTO BLK-PATCHED 32954P
Item not shown
Item Qty. Description Part Number
REPLACEMENT PARTS
*
*
*
