Page 25
REPLACEMENT PARTS
2008 Chrysler XT Conversion (Foldout Ramp) Ramp Assembly
1 1 RAMP ASSY-BASE & EXT/29.25" AUTO E51095??A2909
2 1 ASSY-MAIN RAMP HOUSING E51096A??
3 2 BEARING-FLANGE-5/8" X 1/4"-10FDU04 28435
4 2 SCREW-1/4-20 X 3/8" FLBHSCS- 28252
5 3 BOLT-3/8-16 X 3/4" FLBHSCS-GD8 25171
6 2 PIVOT PIN/BUSHING/EV RAMP/2905 52571-2905
7 1 HARNESS-RAMP EXT./CONTROLLER-OAKTEC 52038A-96A8
8 0.001 LOCTITE-BLUE/#242 GEN PURPOSE 18822
9 1 RETAINER-BEARING 21451-03
10 1 BEARING-1/2ID X 1 1/8 OD-BALL 21371
11 1 WASHER-.519ID X .876OD X .074 12621
12 2 WASHER-.63 X .8 X .06 NYLON{10 83584
13 1 WASHER-UHMW 1.500 OD X .76 ID X 0.062 29680
14 2 WASHER-1/4" EXT STAR TOOTH LOCK ZP 83588
Item not shown
Item Qty. Description Part Number
*
*
*
