BraunAbility Entervan XT - Ramp Gear, Motor, and Base Assembly Parts List

Page 22
REPLACEMENT PARTS
2008 Chrysler XT Conversion (Foldout Ramp) Ramp Assembly Gear, Motor and Base Assembly
Item Qty. Description Part Number
1 1 WMT-MAIN RAMP HOUSING E51096W??
2 1 MOTOR-RAMP ASSY/KLAUBER 12V. 1.2 RPM 51654AK2907
3 1 WMT-ARM-DRIVES RAMP-GEAR MTR E40268W-07BK
4 1 SUPPORT-GEAR MOTOR/FOLDING RAMP/08RT E51179BK
5 1 STOW SWITCH SLIDER E40481
6 4 NUT-SHOULDER 3/4" HEX/0.27 H 32385
7 2 WASHER-NYLON 1/4IDX11/16X.030 12690
8 1 BOLT-1/4-20 X 3" ZN FT/AUTO-BK 23976
9 1 NUT-1/4-20 HEX LOCK/AUTO-BK 10775
10 1 COLLAR-SPLIT-3/4" SHAFT/RMP MTR/INNER/BK 52565-2905BK
11 4 SCREW-1/4-20 X 1" SOC HD CAP 24221
12 1 CAM-MICRO-SWITCH ADJUST-EV 52573-2905
13 1 SCREW-#10-32 X 5/16" SET/AUTO-BK 11562
14 4 SCREW-5/16-18 X 7/8 BUTTON HD W/PATCH 81022
15 1 PLATE-TAPPED #4-40 MICRO SWITCH 24998
16 1 MICRO SWITCH-FLR LVL/CUPPED 34806
17 2 SCREW-#4-40 X 3/4" RD. HD./AUTO-BK 11483
18 4 BOLT-1/4-20 X 1/2 BUT HD SOC/AUTO-BK 15733
19 1 ASSEMBLY-FOLDING RAMP STOW SWITCH 33421A
20 1 NUT-#4-40 w/LOCKWASHER/AUTO-BK 19537
21 1 PIN-RAMP SUPPORT-96SC 29" RAMP 51815-2905
22 1 LATCH BOLT-SUPPORT-29" RAMP 51541-2905
23 4 WASHER-5/16" LOCK/AUTO-BK 10068
24 0.001 LOCTITE-BLUE/#242 GEN PURPOSE 18822
25 1 BOLT-1/4-20X3/4"BHCS NYLK/BKZN 25371
26 2 WASHER-1/4" FLAT/AUTO-BK 10062
27 1 RAMP DEPLY SWITCH ARMATURE GUIDE 34846
Item not shown
Item Qty. Description Part Number
*
*
*
