10
Ventilator Outlets
1
1. Outlet - Main Air Outlet to breathing circuit
Rear Panel Layout
1. Aux. Power - 24 Volt connection for external battery. Connect only
recommended battery, part no 0910.
2. RS232 Port - For connection to remote alarm or personal
computer. Isolated to 1500 Volts.
3. Power Inlet - Input mains power connector. Double fused and
fitted with connector retaining clip.
