29
SPECIFICATIONS
Supply Voltage - 100 - 240 V alternating current
Supply Frequency - 47 - 63 Hz
Maximum Input Current - 0.40 – 1.0 Amperes
Fuse Ratings - 2 x T 1.6 A 20mm
Dimensions (mm) Length - 297 Width - 223 Height - 132
Weight - 3.6 kg (4.5 g with int. battery)
Ambient Operating Temperature - 40
o
C, 104
o
F Max
Digital Output - RS232 Isolated to 1500 Volts
All displayed readings expressed as - ATPD
Max. Output Pressure - 38cm H
2
O(44cm fault condition)
Calibrated pressure Range - 0 - 38cm H
2
O
Accuracy of pressure reading - +/- 3.0% F.S. +/-1% zero
Max. Output Flow - 200 L/min. (unrestricted)
Max Volume Reading - 2000 millilitres
Accuracy of volume reading - Estimated
Inspiratory Trigger - 0.14 – 2.21 L/sec
2
Expiratory Trigger - 0.28 – 1.67 L/sec
2
Inspiratory Time - 0.7 – 3.0 seconds
Back-up Rate - 6 - 43 Breaths per minute
Type of protection against electric shock - Class 1 equipment
Degree of protection against electric shock - Type B to EN 60601-1
Mode of operation - Continuous
IP rating - X0
Storage environment - -20 to 50
O
C
5 – 85% RH
260 – 1100 mBar atmospheric pressure
Internal battery - 18.75Vdc 116Whr
Running time - 4 -12 hours depending on settings and
leak
External battery - 18.75Vdc 116Whr
Running time - 4 -12 hours depending on settings and
leak
Protection against flammable anaesthetic mixtures - Not suitable for use in the presence
of a FLAMMABLE ANAESTHETIC MIXTURE WITH AIR OR WITH OXYGEN OR NITROUS
OXIDE
International Standards
BS EN60601-1 1990, EN 10651-6 EN 10651- 6 2004
Safety of Electromedical Instruments, General Requirements
Electromagnetic Compatibility (In accordance with the EMC Directive 89/336/EMC)
Breas Medical Ltd declares that the NIPPY ST+ Ventilator complies with the following EMC
standards. EN60601-1-2: 1993
Test results available for review from Breas Medical Ltd
0086
