Brent 1082/882 — Set Up
2-5
Bottom Side of
Grain Cart Shown
Drive Line Storage
Behind the Right
Front Support Shown
Basic Set Up (continued)
(April 2015)
Lamp Set Up
Pivot lamp extension arms into position at sides
of cart. The lamp bracket width is adjustable,
if necessary, adjust lamp mount position to
achieve dimension shown. Ensure that the
brackets are adjusted such that the refl ectors
are no more than 16” from outer edge of the
tires. Be sure that amber refl ector is facing
the front of the cart (some lights on certain
cart models will be fl ipped down for shipping).
Drive Line Storage
Storage brackets are located on the inside right frame rail. Secure the PTO shaft to these
brackets for extended transporting or seasonal storage.
• Remove and store the complete PTO before towing grain cart behind a delivery truck. Interfer-
ence could occur when turning resulting in damage to PTO and cart.
Amber Refl ector
To Front of Cart
To Next Page
