5
Step 2: Push the screw inward until the gears on the
opposite side separated from lock position.
Step 3: Adjust the vertical angle of the solar panel (0°, 15°,
30°, 45°, 60°) according to the latitude of your location.
Step 4: Push the gear and tighten the screw until the gears
are securely locked.
MOUNTING KIT INSTALLATION
1. Pole mounting stand x 1 2. Mounting clamp x 1 3. Plastic pole x 1
4. screws x 4 5. Hex nuts x 4 6. Flat washers x 4
7. screw x 1 8. Hex nut x 1 9. Rubber pads x 4
