An optional 3-bale kit is available to allow the Bale King 5300 to carry an extra bale on
the rear of the machine (see page 25). If this kit is installed, an additional clamp is added to the
hydraulic functions. This changes the hydraulic setup as shown in the following table.
5300X – 2 Remote
Control Box
“AUXILIARY”
“FORK”
“DEFLECTOR”
Long Blue
Clamp bale
Lift rear fork
Lift deflector
Long Red
Agitators rotate clockwise
5300X – 3 Remote
Control Box
“FORK”
“DEFLECTOR”
Long Blue
Lift rear fork
Lift deflector
Long Red
Agitators rotate clockwise
Long Green
Clamp bale
5300X – 4 Remote
Long Blue
Lift rear fork
Long Red
Agitators rotate clockwise
Long Yellow
Lift deflector
Long Green
Clamp bale
An optional grain tank kit is available to allow the Bale King 5300 to carry 40 bushels of grain on
the side of the machine (see page 24). If this kit is installed, additional motors are added to the
hydraulic functions. This changes the hydraulic setup as shown below:
5300TR – 2 Remote
Control Box
“AUXILIARY”
“FORK”
“DEFLECTOR”
Long Blue
Discharge grain
Lift rear fork
Lift deflector
Long Red
Agitators rotate clockwise
5300TR – 3 Remote
Control Box
“FORK”
“DEFLECTOR”
Long Blue
Lift rear fork
Lift deflector
Long Red
Agitators rotate clockwise
Long Green
Discharge grain
5300TR – 4 Remote
Long Blue
Lift rear fork
Long Red
Agitators rotate clockwise
Long Yellow
Lift deflector
Long Green
Discharge grain
