27
7.6.5 The user may start (or re-start) monitoring of live CAN data from the sensor (or
entire Backsense network) by pressing the “R” key on the keyboard. Spacebar may
be used to pause live CAN data.
7.6.6 The description for Configuration Tool data is as illustrated below:
RCV =
“Received
Data”
STD =
“Standard
Frame”
CAN1 =
CANpro
Chanel No.
ID 372 =
CAN Message ID Value (Hex)
