II. Steps and Notices for Installation
Installation of cushion block
Install the cushion block as indicated in the figure.
Note:
Get the locating boss on cushion block aligned with the
gap on engine hood.
Adjustment of engine hood lock
Adjustment of clearance of engine hood
Adjustment of height of engine hood
