IV. Right Upper Pillar B
(1) Upper pillar B
(2) Cross recessed pan head self-tapping combined screw (2 pieces, used to fix the part (1))
Dismantlement sequence:
Firstly, remove the sealing strip, and then remove the part (2), pull out the
pillar B, and loose the lower fixing points of seat belt install, and finally pull out the seat belt from the hole,
so as to dismantle the upper pillar B.
Installation:
Install it in the reversed sequence of dismantlement.
