Brilliance V5 2017 - Page 412

109
Connector
Pin No.
Pin definition
Effective level + Remarks
2B.11 (thick)
Rear foglight output
High level
2B.12 (thick)
Ignition switch IGN1 signal
High level
2B.13 (thick)
Ignition switch IGN2 signal
High level
2B.14
N/C
2B.15
IMMO_R
Only for comfortable type car, connected
with pin 11 on engine ECU.
2B.16
Driver door lock unlocking signal
Low level
2B.17
Driver door lock locking signal
Low level
2B.18
Collision signal
2B.19
N/C
2B.20
N/C
2B.21
Ground
2B.22 (thick)
Power supply (+12V)
