7
Installation
1� Determine Installation Location
A� Place the dispenser upright.
B� Locate the dispenser on a hard and level surface in a cool shaded location near a
grounded wall outlet.
NOTICE: Do NOT plug in the power cord until the entire installation section is
completed.
C� Position the back of the dispenser no closer than 20 cm (8 in.) from a wall and
permit free airflow between the wall and water dispenser.
2� Install the Dispenser
WARNING: To avoid a hazard due to instability of the appliance, it must be secured in place in accordance
with the instructions.
A� Loosen and remove the screw on the bottom
left or right of the dispenser.
B� Use this screw to attach the grounding bracket
(J) on the left or right bottom corner of the
water dispenser.
J
C� Make a hole on the surface where the water
dispenser will be installed.
D� Attach the grounding bracket (J) on the surface
by screwing tightly.
J
To Next Page
