Bristan Buzz - Installation - Riser Assembly; Installing the Rigid Riser Assembly; Installing the Wall Bracket

Installing the Rigid Riser
1. Loosen the grub screw on the wall fixing bracket.
2. Assemble the rigid riser and attach to the diverter.
3. Ensure the rigid riser is level and mark the position of the fixing bracket on the wall
surface.
4. Remove the rigid riser from the shower valve
5. Remove the wall fixing bracket from the riser and place on the wall surface at the
market position.
6. Mark fixing holes onto wall surface and drill suitable holes for the fixings supplied.
7. Attached the wall bracket to the wall using fixings supplied.
8. Attach the rigid riser onto the diverter and position riser rail into the wall bracket
ensuring the riser rail is vertical using a spirit level and tighten the grub screw.
9. Attach the rose onto the rigid riser ensuring the sealing and washer is fitted.
10. Attach the shower hose to the diverter ensuring the sealing washer is fitted.
11. Attach the handset to the shower hose, ensuring the sealing washer is fitted.
Installing the wall bracket
1. Mark the position of the wall bracket on the wall surface.
2. Remove the wall bracket fixing using a flat headed screwdriver by pressing the lug.
3. Mark the fixing holes onto the wall surface and drill suitable holes for the fixings
supplied.
4. Attach the wall bracket fixing onto the wall and push the wall bracket onto the wall
bracket fixing.
