Specifications
Inlet Connections: 15mm Compression with 150mm between centres.
Operating Pressure Range: Minimum. 0.5 bar, Maximum 5.0bar.
Maximum Static Pressure: 10.0bar.
Note: Nominally equal (balanced) inlet supply pressures are required for optimum performance.
If pressures are unequal, then a pressure reducing valve should be used.
Maximum recommended imbalance between hot and cold supply should not exceed a ratio of 5:1
Maximum Outlet Temperature: Factory pre-set to 38ºC with push button override to 46ºC (can
be re-set to suit site conditions or personal preference).
Supply Requirements:
Minimum cold water supply temperature: 5ºC
Maximum cold water supply temperature: 25ºC
Maximum hot water supply temperature: 80ºC
(a maximum hot water supply of 60-65ºC is recommended for ablutionary purposes).
Note: The inlet hot water temperature must be at least 10ºC above the required blend
temperature (e.g. outlet temperature 43ºC: Minimum hot supply 53ºC).
