Brivis ICE DO-SC22Z9 - Page 15

Specifications subject to change without notice. © 2013 Brivis Climate Systems Pty Ltd
15
Fig. 12 – Wiring Circuit for Brivis Classic Series Heaters with ICE
Using Brivis Programmable Thermostat
Contact Brivis Technical Support for information on superseded Brivis Heaters.
Y G
R
Electronic Thermostat
W
Refrigeration Compressor
Relay
HCCA621
Fan Speed
G W R
EARTH
Rc
Electronic Control Module
Red LED
C Y
12AC
Fuse 2A
