Brivo ACS300-E - Reader Wiring Details; Wiegand Reader Connections; OSDP RS-485 Reader Connections

Brivo ACS300 Installation Manual Page 20
© 2017 Brivo Systems LLC. All rights reserved. Rev 1
a) Use the wire recommended by the manufacturer of the reader or keypad. If no
wire is recommended, use a minimum of 22 AWG wire with sufficient
conductors that include shield (drain).
b) If your reader interfaces use standard Wiegand conventions, connect the wire
properly to the terminal block on the appropriate board node. Following is a
typical, but not universal, wiring guide. Refer to the Reader/Keypad Wiring Guide
for guidelines related to your specific reader or keypad.
• Connect the green reader wire to the DATA0 terminal. This is the
standard Data 0 circuit for Wiegand readers.
• Connect the white reader wire to the DATA1 terminal. This is the
standard Data 1 circuit for Wiegand readers.
• Connect the black reader wire to the GND terminal. This is the
standard Ground circuit for the reader.
• Connect the blue or yellow reader wire to the BUZZ terminal. This is
the standard Buzzer circuit for the reader.
NOTE: In regards to the BUZZ terminal, please consult the manufacturer’s
wiring instructions to determine the color of the wire.
• Connect the red reader wire to the 12VDC terminal. This provides
+12VDC to power the reader.
• Connect the orange reader wire to the GRN LED terminal. This is the
green LED circuit.
• Connect the brown reader wire to the RED LED terminal. This is the
red LED circuit.
c) If your reader is OSDP using RS-485 wiring conventions, connect the wire
properly to the terminal block on the appropriate board node. Following is a
typical, but not universal, wiring guide. Refer to the Reader/Keypad Wiring Guide
for guidelines related to your specific reader or keypad.
• Connect the green reader wire to the RXD+ terminal. This is the
standard RXD+ circuit for OSDP readers using RS-485.
• Connect the white reader wire to the RXD- terminal. This is the
standard RXD- circuit for OSDP readers using RS-485.
• Connect the black reader wire to the GND terminal. This is the
standard Ground circuit for the reader.
• Connect the red reader wire to the 12VDC terminal. This provides
+12VDC to power the reader.
• Connect the orange reader wire to the TXD+ terminal. This is the
standard TXD+ circuit for OSDP readers using RS-485.
• Connect the brown reader wire to the TXD- terminal. This is the
standard TXD- circuit for OSDP readers using RS-485.
