Brivo ACS300 Installation Manual Page 6
© 2017 Brivo Systems LLC. All rights reserved. Rev 1
Wiring Recommendations
Signal
Belden # or
Equivalent
Twisted
Pair
Conductor
Shielded?
Max
Length
RS-485 Comm, two wire
9841
Yes
Yes
4000 ft
Power (22 gauge)
5504FE
Yes
Yes
600 ft
Power (18 gauge)
6300FE
Yes
Yes
1500 ft
RJ45-Ethernet (CAN Bus)
N/A
Yes
Yes
1500 ft
Fire Alarm Relay
6300FE
Yes
Yes
1500 ft
Request-to-Exit
5520FE/6300FE
Yes
Yes
1500 ft
Door Contact
5500FE
Yes
Yes
1500 ft
Transformer Block
6300FE
Yes
Yes
1500 ft
Molex Connector
N/A
Yes
No
1 ft
Earth ground
N/A
Yes
Yes
20 to 40 ft
Reader Option 1 (22 AWG)
5504FE
Yes
Yes
250 ft
Reader Option 2 (20 AWG)
5400FE
Yes
Yes
300 ft
Reader Option 3 (18 AWG)
6300FE
Yes
Yes
500 ft
Additional Resources
The following additional resources are available for the installer as well as the client.
Panel Networking Admin Interface Guide
Reader/Keypad Wiring Guide
Brivo OnAir Quick Start Guide
Brivo Cellular Network Router Configuration Guide
Brivo OnSite Server Quick Start Guide
Brivo OnSite Quick Start Guide
Brivo OnSite Administrator’s Manual
Technical Support: 1-866-BRIVO-4-U
www.brivo.com
